Author: Subject: Sodium Chromate from stainless stell 18/10
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 30-9-2012 at 04:56


If it was colloidal it would probably run through the filter, like a solution. Fe(OH)3 has a tendency to do that and I've seen it happen: allof a sudden your precipitate ends up at the wrong side of the firlter, very annoying. But that didn't happen here... It's called peptisation. 'Sn(OH)4' does it too.



View user's profile Visit user's homepage View All Posts By User
plante1999
International Hazard
*****




Posts: 1937
Registered: 27-12-2010
Member Is Offline

Mood: Mad as a hatter

[*] posted on 30-9-2012 at 05:19


@ blogfast:

I think he would be better to use my procedure, more straight forward and more robust not to mention simpler.
He seam to have some difficulties with the peroxide method.





I never asked for this.
View user's profile View All Posts By User
Salmo
Harmless
*




Posts: 42
Registered: 20-9-2012
Member Is Offline

Mood: No Mood

[*] posted on 30-9-2012 at 08:29


Man i really dont know what it was, I just can tell you that it was a really thick sludge that wasn't forming any kind of precipitate, it was more like a fucking gel impossible to vacuum filter. Anyway as I'm bored to use nasty HCl at home :), tomorrow I will electrolyze a big spoon in a NaCl solution, I did it before with good results, then I will precipitate everything with NaOH, add peroxide and than filter the mass to obtain the chromate solution, i will post photos!
Plante your procedure is for sure better and faster I have to obtain some sodium nitrate first, can yuo tell me your exact procedure?
View user's profile View All Posts By User
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 1-10-2012 at 09:46


Quote: Originally posted by plante1999
@ blogfast:

I think he would be better to use my procedure, more straight forward and more robust not to mention simpler.
He seam to have some difficulties with the peroxide method.



To make such a statement a robust comparison between the methods would need to be made first. I started of with some kind of fusion (KOH + KClO3), only to find it wasn't necessary: everything can be done at RT and in solution/slurry.

An example of separating the Cr from an FeCr heating element, here:

http://www.sciencemadness.org/talk/viewthread.php?tid=21298#...

Still, why not post the details of your [plante] approach here?

[Edited on 1-10-2012 by blogfast25]




View user's profile Visit user's homepage View All Posts By User
plante1999
International Hazard
*****




Posts: 1937
Registered: 27-12-2010
Member Is Offline

Mood: Mad as a hatter

[*] posted on 2-10-2012 at 12:53


You have it right on the point that I should upload it, I would prefer to do a prepublication about it tough. I tried both and found the peroxide way a lot harder to do because of colloidals, concentrations of solution not to mention a lot more costly than hydroxide melt.



I never asked for this.
View user's profile View All Posts By User
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 3-10-2012 at 07:30


Well, let us know when the prepublication is up.



View user's profile Visit user's homepage View All Posts By User
tetrahedron
Hazard to Others
***




Posts: 210
Registered: 28-9-2012
Member Is Offline

Mood: No Mood

smile.gif posted on 12-10-2012 at 16:53


Quote: Originally posted by plante1999
I also used electrolysis of S.S in a carbonate electrolite but I found it energy intensive and take time to make some chromate but Hasslefree.


sounds interesting..do you have any more details on this? do you add any oxidizer to the electrolyte?

Quote: Originally posted by plante1999
use molten sodium hydroxide mixed with sodium nitrate for the chromium extraction from the dry mass


i just did the potassium version of this. after filtering out the largely unreacted Cr2O3 i got a yellow solution that i'll quantitate asap.
View user's profile View All Posts By User
plante1999
International Hazard
*****




Posts: 1937
Registered: 27-12-2010
Member Is Offline

Mood: Mad as a hatter

[*] posted on 12-10-2012 at 17:32


Only electrolysing S.S at 20V in Na2CO3 electrolyte. Sodium chromate go in to solution but iron and nickel don't. It take a large amount of time to get a product but it work really well. If molten for enough time all the Cr2O3 will react. Use stochiometry to know hydroxide/nitrate ratio.




I never asked for this.
View user's profile View All Posts By User
12AX7
Post Harlot
*****




Posts: 4803
Registered: 8-3-2005
Location: oscillating
Member Is Offline

Mood: informative

[*] posted on 12-10-2012 at 19:46


If you have an oxidizer such as KNO3 or KClO3 on hand, you can perform a fusion:
http://webpages.charter.net/dawill/tmoranwms/Chem_Chromate.h...
The KCl and NaOH aren't necessary; with KClO3 at least, the reaction proceeds under "acidic" conditions, yielding KCl and K2Cr2O7 directly (but beware the fumes, exotherm and decomposition).

This may not work with ashed* stainless, because nickel or iron are probable catalysts for decomposition. I once tried the reaction on mixed oxides where chrome was known to be present; all I got was frothing (decomposition, O2) and a lot of black stuff.

It's noteworthy that molten KClO3 is reasonably stable in a steel or stainless crucible.

*By 'ashed', I mean oxidized, dried, powdered material. It could be burned in air (well, if you can about melt the stuff; it doesn't oxidize very fast otherwise), dissolved in acid and precipitated wholesale (mixed hydroxides), calcined, etc.

On a related topic, I seem to recall PbO2 can also be made by a similar method, but I'm not set up to test it.

Tim




Seven Transistor Labs LLC http://seventransistorlabs.com/
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!
View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 13-10-2012 at 05:17


Hi Tim,

It's quite similar to treating Chromite (FeCr2O4) with KOH/KNO3, then leaching. The iron stays, the chromate is lixivated off. Nice page!




View user's profile Visit user's homepage View All Posts By User
violet sin
International Hazard
*****




Posts: 1385
Registered: 2-9-2012
Location: Back yard staring at stars
Member Is Offline

Mood: Good

[*] posted on 13-10-2012 at 05:58


so I have been messing around with the idea of purifying the chromite ore I found, but along the way just wanted to see if I could make Na2Cr2O7 from pure Cr metal. and I think I have come up with a pretty darn easy way.

I made a decently strong NaOH solution and immersed a ~99.1% chunk of ebay Cr metal(+) electrode and a Ti(-). the solution turns bright yellow after a short while, because of deep orange gel pouring off the Cr electrode. this worked so far... the colors were right. I figured ok let it run a while build up a concentration. it developed a darker(greyish) cast and became more opaque. My only guess was that there was no longer any sodium to keep up with the dissolving Cr. there were some small fragments of Cr metal so I figured maybe I can add H2O2 and or lye to see if I could oxidize it after providing more Na ions. both caused bubbles and heat. after filtering w/ coffee filter I found a grey gel with the tiny bits of Cr glimmering in it, and a BRIGHT yellow clear solution. this was good for the chromate I thought, and after adding a small amount of H2SO4 drop-wise to the solution it became decidedly orange! again I figured I was on the right path. the H2SO4 didn't noticeably fight with NaOH as no bubbles were evolved. figured this meant the sodium was used up.
I put this flask in a water bath just below boiling, and waited patiently. went from 125ml --> ~50 ml before I noticed anything. orange crystals at the edge of the liquid. filtered it around 30ml and got a decent amount of orange crystals. though they don't seem to be too regular. need to recrystalize after washing w/ ice water. my 12th merck said that sodium dichromate aq. can be set to ~100 for a prolonged time to make anhydrous. I deff had crystals and didn't see any breakdown, and the onely elements I introduced were Cr, NaOH, H2O, with a bit of H2SO4, and H2O2. so given the behavior and colors I figure I have Na2Cr2O7 :) though tired now and ready for bed 6:30am...


but seems pretty simple to use NaOH sol. and slap a Cr electrode in there. then throw a small amount of juice at it. my cell(250ml Erlenmeyer) needed to be put in a buffering water bath. not cooling but to tame against thermal shock. my power supply was an OLD hacked ATX computer spare.

maybe tomorrow I can figure out how to get some pic's up. gotta buy some more gloves also. if some one thinks I may have performed some other reaction then please enlighten me. but I feel fairly confident. if it did work I don't see why this couldn't be adapted to the use of Stainless Steel. though I would stay the heck away from HCl with this stuff. chromyl chloride isn't for me.... I know that in the test run of this I used a stainless nail to make contact to the Cr metal. the Fe contamination just turned to a brown gelly at the bottom, and man does Ni drop out of solution with NaOH in there. ( just got done making nickel chloride, sulfate, acetate and hydroxide last week). any thoughts?

[Edited on 13-10-2012 by violet sin]
View user's profile View All Posts By User
Salmo
Harmless
*




Posts: 42
Registered: 20-9-2012
Member Is Offline

Mood: No Mood

[*] posted on 13-10-2012 at 06:43


Ok finally I did it!
I told you that I would have posted my procedure and the photos so here I am.
I started from 18/10 stainless steel from a fork, I electrolyzed it in a 25% NaCl solution with my lab power supply adding some 33% HCl to destroy the hydroxides formed. than I stopped it after 2 hours and I filtered the solution to obtain a clear green solution.
Than I added a saturated Na2CO3 solution to precipitate iron/nickel and chromium as hydroxides, I didn't use a NaOH solution because strong sodium hydroxide solutions react with chromium hydroxide to form soluble [Cr(OH)6]3-.
Anyway after the precipitation I filtered the solution and I obtained a dark green/brown sludge that I washed with water. Than heating the sludge, I added a really strong NaOH solution to it,and than 35% H2O2, 10ml a time, to oxidize Na3[Cr(OH)6] to sodium chromate, so the sludge after lot of fizzing, turned brown and I filtered it obtaining a yellow sodium chromate solution.
So because I wanted to remove the excess of NaOH, NaCl and everything else I added HCl to the sodium chromate solution until acid, I reduced it adding hydrogen peroxide again and I precipitated Cr(OH)3 adding sodium carbonate.
I washed my chromium hydroxide with hot water many times and I obtained a blue mass that I redissolved with as little as I could of a strong NaOH solution than I added the right amount of H2O2 and I heated the solution, after filtering I got a really strong yellow sodium chromate solution.
Now I checked the pH of the solution and it is high so I have some sodium hydroxide in it, do you know how can I remove it for the last time?? I thought to sulfuric acid until pH 7 maybe sodium sulfate is easy to remove.. I dont know
Damn I want an induction heater and damn believe me filtering hydroxides or oxides is time consuming and a pain in the ass.



20121008_153242.jpg - 100kB 20121008_190933.jpg - 95kB 20121010_172043.jpg - 58kB 20121010_213835.jpg - 64kB 20121010_222850.jpg - 99kB 20121012_160937.jpg - 68kB 20121012_171437.jpg - 65kB 20121012_173544.jpg - 46kB 20121012_183922.jpg - 70kB

[Edited on 13-10-2012 by Salmo]
View user's profile View All Posts By User
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 13-10-2012 at 12:14


Well done, Salmo.

Two comments:

Quote: Originally posted by Salmo

Than I added a saturated Na2CO3 solution to precipitate iron/nickel and chromium as hydroxides, I didn't use a NaOH solution because strong sodium hydroxide solutions react with chromium hydroxide to form soluble [Cr(OH)6]3-.

[snip]

Now I checked the pH of the solution and it is high so I have some sodium hydroxide in it, do you know how can I remove it for the last time?? I thought to sulfuric acid until pH 7 maybe sodium sulfate is easy to remove.. I dont know


Your reasoning is correct but chromite [Cr(OH)4(-)] does not appear to form when large amounts of iron are also present (as is the case here). In those circumstances, the Cr3+ appears to co-precipitate fully with the iron oxide(s). But as you’ve seen later on, Cr(OH)3 on its own does dissolve in strong NaOH to form sodium chromite.

Re. removing the remaining peroxide. DO NOT acidify at this point because in acidic conditions the excess peroxide will reduce the chromate back to Cr (III)! The best way of destroying left over hydrogen peroxide is to simmer your solution for some time. Then take attest tube sample and acidify it. It should revert to the yellow/amber of dichromate. If any blue/green appears, you’ve still got peroxide left.

Re. removing the excess NaOH. For dichromates usually the K salt is preferred, I believe because K2Cr2O7 is only sparingly soluble in cold water and thus easier to isolate. The excess KOH would be neutralised with H2SO4 and on cooling crystals of K2Cr2O7 would appear, provided you started from about the right amounts of KOH and Cr. I’m not sure how this will pan out with Na2Cr2O7.

Nice photos!



[Edited on 13-10-2012 by blogfast25]




View user's profile Visit user's homepage View All Posts By User
violet sin
International Hazard
*****




Posts: 1385
Registered: 2-9-2012
Location: Back yard staring at stars
Member Is Offline

Mood: Good

[*] posted on 13-10-2012 at 22:17


so was there anything wrong with the route I took? I don't have Ph test strips and reagents are quite limited.

composit.bmp - 728kB

the crystals aren't defined well in the cigar tube b/c I didn't have time to do anything but give 'em a quick rinse in the filter. were there any concerns of contamination? other than Na2SO4? blogfast25 you said something about soluble chrome hydroxides but not to worry in an alkaline setting? just been having fun with the electrochem and a few of the metals I collect.
View user's profile View All Posts By User
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 14-10-2012 at 05:13


VS:

Is that sodium dichromate or potassium dichromate in the cigar tube? To purify further, recrystallise.

Nice work!

Re. Cr(OH)3 and chromites, see further upthread...




View user's profile Visit user's homepage View All Posts By User
Salmo
Harmless
*




Posts: 42
Registered: 20-9-2012
Member Is Offline

Mood: No Mood

[*] posted on 14-10-2012 at 06:08


Thanks blogfast today I will acidify drop by drop with sulfuric acid to ph 7 and than I will try to separate the Na2SO4 using its different solubility.
Na2SO4 is 4.9g/100ml ( at 0°C) and sodium chromate is 163g/100ml ( at 0°C).
Violet sin, I think you have my same problem, the fucking sodium! anyway good job now recrystallise.
Check this site: http://www.chemguide.co.uk/inorganic/transition/chromium.html

[Edited on 14-10-2012 by Salmo]
View user's profile View All Posts By User
violet sin
International Hazard
*****




Posts: 1385
Registered: 2-9-2012
Location: Back yard staring at stars
Member Is Offline

Mood: Good

[*] posted on 14-10-2012 at 08:57


blogfast: thanks that is the Na salt. obviously not pure as I am reading in "atboic:Cr" from the reference section right now. thought the stuff in the cigar tube is from the first stuff to fall out from water bath reduction, and more likely pure(er)...

facing Cr(OH)3 and the chromites it makes with NaOH... gotcha

from what I gather you are saying, starting off with a strong NaOH sol for electrolyzing means I have the Na3[Cr(OH)6] and Na[Cr(OH)4] from the moment Cr oxidizes into solution? -but- it can be oxidized from the -ite to the chromate with H2O2 in it's alkaline situation. then further boiling I would get rid of extra hydrogen peroxide, before H2SO4 acidification to the dichromate( which I wanted for conversion ). but I only really have a bit of Na sulfate salt contaminant from neutralization of excess NaOH *IF* I managed to get all of the odd hydroxide complex completely oxidized to chromate first *AND* I boiled it long enough to kill the H2O2 before acid so it doesn't revert to the chromite correct?
the grey gel I had with the sparkly bits in it may be the hydroxide 'aging out', and as a result of Cr3+ from adding the H2O2 in acidic conditions? explains why it got cloudy a few times( playing with H2O2)

or is there still a chromite that is not solved by oxidation to chromate with H2O2? I only have 3% so it is a LOT of fun to add and boil down. if there was any left over then it is surely gone by the time I through with it's water... those older books are kinda hard to get the hang of,, having to rearrange stuff in your head for hydrated forms or odd oxides that are a mix of two other oxides. I say if you haven't been doing that for a while it's a real treat to try and keep it all straight

thanks also salmo nice info site. like it. I think the reason for doing it in Na form is the merk says it will be fine to dehydrate --> anhydrous by water bath or @ ~100'C for extended time w/o decomp probs. then it would be easy to add water necessary and do the KCl dance quickly. that's my end goal with this exploration, no reason just looks fun. I just wish I could accidify it with something that didn't have a fun salt leftover like Na2SO4

[Edited on 14-10-2012 by violet sin]
View user's profile View All Posts By User
12AX7
Post Harlot
*****




Posts: 4803
Registered: 8-3-2005
Location: oscillating
Member Is Offline

Mood: informative

[*] posted on 14-10-2012 at 14:09


Chromates are very strong in color and stain everything, so you could have sodium sulfate with surprisingly little (di)chromate. Not sure if they form solid solutions; I suppose chromate (but not di-) could partially substitute sulfate.

One easy way to tell, take some crystals and attempt to dry or melt them. Sodium sulfate hydrate decomposes under low humidity conditions, or melts in its water of crystallization, IIRC around 80C.

Precipitating with potassium has the downside that K2SO4 is also fairly low solubility. Ditto ammonium.

Using HCl instead of H2SO4 would be better; both KCl and NaCl have good solubility at all temperatures.

Tim




Seven Transistor Labs LLC http://seventransistorlabs.com/
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!
View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
violet sin
International Hazard
*****




Posts: 1385
Registered: 2-9-2012
Location: Back yard staring at stars
Member Is Offline

Mood: Good

[*] posted on 14-10-2012 at 15:50


well it would be hard to have too much Na2SO4 in there b/c I only had to use a few ml of H2SO4 to acidify to orange, whereas my chromium metal chunk went from a nice angular shattered look to a well worn beach pebble. I think in the entire 250ml flask I used ~5ml for shift(<10ml, was only a 1ml eye dropper). that leads me to believe that I used up most of the NaOH forming the sodium chromate and chromite that got oxidized so ya chromate( as I used 4-5 Tbs. NaOH). I stopped energizing once I noticed a greyish opacity(Cr(OH)3), then filtered. that was more than likely the solution ppt out Cr(OH)3 because of lack of free OH- to solovate. then oxidized and acidified. so I was deff on the right track but had the hydroxide/chromite like blogfast n salmo said. not saying you are wrong just I don't think I had a lot of sulfate...

looking back after the last few very helpful posts, I dissolved everything again this morning and added H2O2 back to clear yellow. only a small pile of clean Cr crumbs were left in the eddy after much bubbling and quite a few additions. seemed I had a rather sizable amount of Cr(OH)3/chromite. I left it to simmer @~90'C for like an hour to boil down and kill H2O2.

I did notice when dissolving crystals again that something was wrong, took more water & time than it should have, so quite glad I cleaned it up. I like the dry melt idea, shoulda looked up more physical traits to compare before declaring DONE. good point. no HCl for me with Cr, afraid of the chromyl chloride. I have less than ideal ventilation... no thanks. working on a dimmer-switched vent fan/hood and ducting today as well. construction background comes in handy yet again :)

trying to get some pictures up for re-polished product soon. also started a small batch from stainless nails. doing everything salmo did just on a 50ml scale just for shitts and giggs. salt works surprisingly well for devouring SS
View user's profile View All Posts By User
12AX7
Post Harlot
*****




Posts: 4803
Registered: 8-3-2005
Location: oscillating
Member Is Offline

Mood: informative

[*] posted on 14-10-2012 at 17:11


Yup, if there's a lot more chrome than sulfate then it's probably not going to show up.

Chromyl chloride isn't a concern, as far as I know: it hydrolyzes rapidly in water. A bigger concern would be dichromate oxidizing chloride to chlorine and reducing your yield, but I think this is unfavorable too, and in any case not a problem if an excess of acid is not added.

Tim




Seven Transistor Labs LLC http://seventransistorlabs.com/
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!
View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
Salmo
Harmless
*




Posts: 42
Registered: 20-9-2012
Member Is Offline

Mood: No Mood

[*] posted on 15-10-2012 at 04:24


Today I will try to purificate my sodium dichromate solution removing all the sodium sulfate inside, i will boil down the solution to 10ml than I will put it in the fridge to 0°C hoping to see some sodium sulfate precipitation but anyway it's hard that i will obtain something pure..i think that solid fusion is the best idea because it's so difficult to add the right amount of NaOH during the oxidation and adding too much means a not pure product full of NaCl or Na2SO4..

[Edited on 15-10-2012 by Salmo]
View user's profile View All Posts By User
blogfast25
Thought-provoking Teacher
*****




Posts: 10340
Registered: 3-2-2008
Location: Old Blighty
Member Is Offline

Mood: No Mood

[*] posted on 15-10-2012 at 09:24


Yes, separating the chromate/dichromate from neutralisation by-products may prove to be the hardest part here.

Obviously, however you want to make these Cr (VI) salts, the trick is to keep by-products to a minimum by working as close to stoichiometry as possible. Small amounts of soluble by-products should then always remain in solution. So as with any decent synthesis, planning ahead is crucial.

Tim’s right about the solubilities, KCl is somewhat more soluble than K2SO4. HCl also has the advantage that it’s volatile so that any excess will evaporate on drying your end-product.

The solubilities for the Na and K dichromates at 0 C (Wiki solubility table) are resp. 163 [that sounds really high!] and 4.7 g/100 ml, so for dichromates the alkali of choice should be KOH,H2O2 as oxidiser and HCl as neutraliser. Unless you want to use fusion.


[Edited on 15-10-2012 by blogfast25]




View user's profile Visit user's homepage View All Posts By User
tetrahedron
Hazard to Others
***




Posts: 210
Registered: 28-9-2012
Member Is Offline

Mood: No Mood

[*] posted on 15-10-2012 at 09:50


Quote: Originally posted by plante1999
Only electrolysing S.S at 20V in Na2CO3 electrolyte. Sodium chromate go in to solution but iron and nickel don't. It take a large amount of time to get a product but it work really well.


i've been running this the whole day, using a chrome plated stainless steel fork for anode and a graphite cathode. the chrome plating resisted corrosion so well that i had to temporarily hike the voltage to almost 40V before the electrolyte caught color (a previous addition of H2O2 didn't help). i'm finding it hard to keep the voltage that high as my PSU maxes out at 6A. i had to increase resistance by reducing the anode surface dipping in the electrolyte, but this feels wrong from an efficiency standpoint. does it necessarily have to be that high to oxidize the Cr to +6?
View user's profile View All Posts By User
12AX7
Post Harlot
*****




Posts: 4803
Registered: 8-3-2005
Location: oscillating
Member Is Offline

Mood: informative

[*] posted on 15-10-2012 at 16:16


Hmm, K2CrO4 has higher solubility than K2Cr2O7. Might be useful. pH swing crystallization or something? Take your impure mixture, add an estimated stoich amount of KOH, wait to dissolve; evaporate to saturation, then add HCl. KCl and NaCl stay put (unless they are also at saturation, in which case the added chloride may drop a small amount; a second pass should be clean).

And, of course, collect all wastes and crystallize out all the orange and not-orange stuff and repeat...

Tim




Seven Transistor Labs LLC http://seventransistorlabs.com/
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!
View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
plante1999
International Hazard
*****




Posts: 1937
Registered: 27-12-2010
Member Is Offline

Mood: Mad as a hatter

[*] posted on 15-10-2012 at 17:19


Quote: Originally posted by tetrahedron
Quote: Originally posted by plante1999
Only electrolysing S.S at 20V in Na2CO3 electrolyte. Sodium chromate go in to solution but iron and nickel don't. It take a large amount of time to get a product but it work really well.


i've been running this the whole day, using a chrome plated stainless steel fork for anode and a graphite cathode. the chrome plating resisted corrosion so well that i had to temporarily hike the voltage to almost 40V before the electrolyte caught color (a previous addition of H2O2 didn't help). i'm finding it hard to keep the voltage that high as my PSU maxes out at 6A. i had to increase resistance by reducing the anode surface dipping in the electrolyte, but this feels wrong from an efficiency standpoint. does it necessarily have to be that high to oxidize the Cr to +6?


Like I already said, It take time is inefficient , but It work. If your S.S is hard to dissolve use Sodium bicarbonate electrolyte, It should help for the dissolution of the Chromium. The idea is that the Ph is lowered increasing corrosion of iron.




I never asked for this.
View user's profile View All Posts By User
 Pages:  1  2    4  5

  Go To Top
