Author: Subject: Drying pseudonitrosites
chemist1243
Hazard to Others
***




Posts: 168
Registered: 7-8-2019
Member Is Offline


[*] posted on 12-3-2021 at 11:21
Drying pseudonitrosites


Ref:
https://erowid.org/archive/rhodium/chemistry/pseudonitrosite...

In this paper, it is emphasized that pseudonitrosite dimer be vacuum dried and then air dried before the reaction with alcoholic KOH. Yet it is stated that the pseudonitrosite decomposes quickly upon storage producing HCN and Nitrogen oxides. vacuum filtration is not available to me right now, and I’m unsure if air drying is even safe due to the short decomposition time.

Must the reaction between the pseudonitrosite dimer and alcoholic KOH be anhydrous? if so, what is the maximum amount of time you could safely allow the pseudonitrosite to air dry?

View user's profile View All Posts By User
dawt
Hazard to Self
**




Posts: 73
Registered: 9-5-2016
Location: EU
Member Is Offline

Mood: fluorescent

[*] posted on 12-3-2021 at 11:45


Doesn't need to be anhydrous. Leaving the pump running for a minute or two after the filtration works well, but if you don't have access to one you might try putting your filter on a paper towel after filtration to get rid of more moisture?

At room temperature the pseudonitrosites visibly begin discolouring after a few minutes. If you're left with a fine precipitate this might cause you some headaches if the gravity filtration takes too long.
View user's profile Visit user's homepage View All Posts By User
chemist1243
Hazard to Others
***




Posts: 168
Registered: 7-8-2019
Member Is Offline


[*] posted on 12-3-2021 at 11:57


Thanks so much, this is great info. do you have any references, or are you speaking from experience?
View user's profile View All Posts By User
dawt
Hazard to Self
**




Posts: 73
Registered: 9-5-2016
Location: EU
Member Is Offline

Mood: fluorescent

[*] posted on 12-3-2021 at 12:06


I messed around with eugenol many years ago, making all sorts of derivatives to see what they smelled like. Made pseudonitrosites two or three times. If I remember correctly the yield was greatly improved by keeping the reaction mixture in an ice bath during the gassing with N2O3, and starting the workup immediately after the color change. You'll see what I mean when you run the reaction. :)
View user's profile Visit user's homepage View All Posts By User
chemist1243
Hazard to Others
***




Posts: 168
Registered: 7-8-2019
Member Is Offline


[*] posted on 12-3-2021 at 12:35


Ah, so the dimerization of the pseudonitrosite is quite rapid then? I assume it clears up within a few minutes after the initial change. No wonder why they got such low yeilds in my reference; they gave it hours to waste away, and probably didnt keep it cool enough for the maximum amount of N2O3 to stay in solution.

Thank you so much, this has been of great help! (:
View user's profile View All Posts By User
dawt
Hazard to Self
**




Posts: 73
Registered: 9-5-2016
Location: EU
Member Is Offline

Mood: fluorescent

[*] posted on 12-3-2021 at 14:55


IIRC the gassing took a few hours... Memory's a bit hazy since it was so long ago. Pretty sure I generated the N2O3 in situ at first and wasn't happy with the results, so I set up an external N2O3 generator on my second attempt and made a few more changes, as described above.
Try purging your apparatus of oxygen before making the N2O3, or you'll get a bunch of brown NO2... Instantly and permanently discolored my PVC tubing.
View user's profile Visit user's homepage View All Posts By User
clearly_not_atara
International Hazard
*****




Posts: 2313
Registered: 3-11-2013
Member Is Offline

Mood: Big

[*] posted on 12-3-2021 at 14:57


Think about it this way: what do you expect to be harder to dry, the pseudonitrosidte or the KOH? Because once they're in the same phase it's all the same. Anhydrous KOH is way harder than some oily organic compound.



[Edited on 04-20-1969 by clearly_not_atara]
View user's profile View All Posts By User
dicyanin
Harmless
*




Posts: 36
Registered: 29-3-2020
Location: Belgique
Member Is Offline

Mood: inquisitive

[*] posted on 10-5-2021 at 08:14


It never was an issue for me as the pseudonitrosite is washed a few times with alcohol and finally with ether.



There are more things in heaven and earth,
Horatio,
Than are dreamt of in your philosophy
View user's profile View All Posts By User
zed
International Hazard
*****




Posts: 2269
Registered: 6-9-2008
Location: Great State of Jefferson, City of Portland
Member Is Offline

Mood: Semi-repentant Sith Lord

[*] posted on 12-5-2021 at 04:35


"Must the reaction between the pseudonitrosite dimer and alcoholic KOH be anhydrous?"

Interesting question. Technically, Alcoholic KOH cannot be anhydrous. There is an equilibrium wherein KOH+Alcohol<--->K-Alkoxide+H2O. Alcohol can be anhydrous. Potassium Hydroxide can be anhydrous. Potassium Ethoxide can be anhydrous. But, Alcohol plus KOH... No. Just part of the deal.




[Edited on 12-5-2021 by zed]

[Edited on 12-5-2021 by zed]
View user's profile View All Posts By User
dicyanin
Harmless
*




Posts: 36
Registered: 29-3-2020
Location: Belgique
Member Is Offline

Mood: inquisitive

[*] posted on 13-5-2021 at 06:08


Pondering over the stability of pseudonitrosites, I remembered I still had a sample of isodillapiole in my collection, so I decided to do an experiment.


Preparation of isodillapiole pseudonitrosite

A solution of 20.7 g (0.3 mol) sodium nitrite in 35 ml distilled water was prepared and added to a 500 ml round-bottom flask with stirbar. A solution of 6.6 g (0.03 mol) isodillapiole [1] in 50 ml diethyl ether was added, the flask fitted with a Claisen adapter, an addition funnel, and an outlet to vent the noxious fumes outside. The flask was placed in an ice/water bath (with plenty of ice) on a magnetic stirrer. In the addition funnel was placed 75 g 20% sulfuric acid. The acid was added dropwise to the stirring two-phase mixture over a period of 3 hours. (using the principle "when you see brown NO2 fumes you're adding the acid too fast.")

At about 1/5th of the acid added, a cloudiness was observed. This then turned into a thick cream-coloured precipitate towards the end of the addition. It was left stirring in the ice/water bath an additional hour. Air was pumped in through the addition funnel using an aquarium air-pump to remove as much nitric oxide fumes as possible from the system before opening it.

The mixture was filtered using gravity filtration through 2 coffee-filters (obviously this should be done in a well-ventilated area). The obtained solids were washed with distilled water, 4x with methanol and finally with a good portion of diethyl ether. When gravity filtration is done, the filter is pressed by hand against the funnel as to remove as much solvent as possible. Then it was air dried for 1 hour. Tan coloured crystals of isodillapiole pseudonitrosite were obtained.

They weighed 15.3 grams after air drying for over an hour. My impression is that the solids seem to absorb some of the ether. It is not easy to get them to completely dry like this. I took a 0.3 gram sample of the pseudonitrosite in a capped sample contained to observe the decomposition rate. As I am typing this, the sample is still white and crystalline after 48 hours, no brown NO2 fumes can be seen, there are still no signs of decomposition.
The reason why I did this experiment was in the first case to observe the stability of pseudonitrosites at first hand. At least for isodillapiole, it is much more stable than often assumed.


[1] The isodillapiole used in this experiment was prepared about six months ago. It was obtained by refluxing dillapiole in 4M ethanolic KOH for 15 hours. The product was isolated following common procedure and recrystallised twice from petroleum ether. A yellowish-white crystalline product was obtained that darkened somewhat on standing. The dillapiole was obtained from fractionation of Indian dill seed oil (Anethum sowa), it is the main fraction after removal of carvone.


setup.jpg - 295kB addition.jpg - 224kB end of addition.jpg - 228kB pseudonitrosite two-phase.jpg - 264kB gravity filtration PN.jpg - 100kB gravity filtration after washing.jpg - 142kB gravity filtration PN pressing out.jpg - 204kB pseudonitrosite-dillapiole washed and dried.jpg - 173kB pseudonitrosite 2.jpg - 82kB




There are more things in heaven and earth,
Horatio,
Than are dreamt of in your philosophy
View user's profile View All Posts By User
dicyanin
Harmless
*




Posts: 36
Registered: 29-3-2020
Location: Belgique
Member Is Offline

Mood: inquisitive

[*] posted on 13-5-2021 at 06:15


Preparation of beta-nitroisodillapiole

The above pseudonitrosite was added in small portions to a strongly stirred chilled solution of 50 ml 8% ethanolic KOH [2], placed in an ice/water bath. The temperature was 2-3°C during addition. Only minimal foaming was noted, after addition the mixture was stirred for an additional 30 minutes. It was then filtered, again using gravity filtration (through a single coffee-filter), and the solids washed with a portion of ethanol, added to the filtrate. [3]

The filtrate was poured on 30 grams of crushed ice, and the mixture was carefully acidified by adding 50 ml 5% aq. HCl in small portions with stirring, so that the temperature was never allowed to rise above 10°C. A fine, canary-yellow precipitate was obtained, which was isolated again by gravity filtration (through 2 coffee-filters). The precipitate was washed with ice-cold water, and the washing added to the filtrate which made it turn cloudy. After standing for 24 hours a (small) second crop is obtained from this as yellow needles. The first crop weighed 2.2 g and the second 0.4 g so the total yield of beta-nitroisodillapiole was 2.6 g (32% based on isodillapiole).


[2] The ethanol used was technical grade 95% denatured ethanol, sold as "bio alcohol fuel". The denaturant agent is unlisted, but on dissolving KOH the (initially clear) solution turned an orange colour.

[3] These beige coloured solids were suspended in boiling ethanol, filtered again, and dried and saved. As such 9.0 grams of potassium hyponitrite (K2N2O2) were obtained as a white solid. This is in itself an interesting compound, it can be used as reducing agent and the corresponding acid is a tautomer of nitramide.


In previous experiments (long ago I admit) I was never able to obtain the higher yields mentioned in the pseudonitrosite FAQ. Results were always in the range of the above using other substrates too.



addition of PN to alcoholic base.jpg - 216kB hyponitrite filtration.jpg - 208kB beta-nitro-isodillapiole first crop.jpg - 296kB beta-nitro-isodillapiole second crop.jpg - 230kB final result.jpg - 257kB




There are more things in heaven and earth,
Horatio,
Than are dreamt of in your philosophy
View user's profile View All Posts By User
dicyanin
Harmless
*




Posts: 36
Registered: 29-3-2020
Location: Belgique
Member Is Offline

Mood: inquisitive

[*] posted on 13-5-2021 at 06:17


This is the sample of isodillapiole pseudonitrosite I kept in a capped container. It is now 2 days and 2 nights after the experiment and I still can't see any clear signs of decomposition.

PN sample 48h -1.jpg - 89kBPN sample 48h -2.jpg - 53kB




There are more things in heaven and earth,
Horatio,
Than are dreamt of in your philosophy
View user's profile View All Posts By User
Boffis
International Hazard
*****




Posts: 1703
Registered: 1-5-2011
Member Is Offline

Mood: No Mood

[*] posted on 13-5-2021 at 09:09


Nice work dicyanin! I must admit that I have never had need to prepare pseudonitrosites but the ability to recovery the hyponitrite is intriguing.
View user's profile View All Posts By User
dicyanin
Harmless
*




Posts: 36
Registered: 29-3-2020
Location: Belgique
Member Is Offline

Mood: inquisitive

[*] posted on 14-5-2021 at 03:01


Thank you. I've always found it a very elegant reaction. And I'm more interested in the chemistry muse, than in the product obtained by taking it a step further. My capped sample of isodillapiole pseudonitrosite still shows no visible signs of decomposition, it is still white and no sign of brown NO2 fumes when holding it against a white background. I wonder if all pseudonitrosites are more stable than we assumed, or if it is just this particular substrate?

Maybe it would it an idea to use paper indicators to measure decomposition?

The hyponitrite has some interesting points. It can reduce iodine, and the corresponding acid apparently has energetic properties. It must be prepared from silver(I)hyponitrite in strictly anhydrous conditions though. Merely acidifying K2N2O2 will result in generation of N2O, laughing gas.

https://en.wikipedia.org/wiki/Hyponitrous_acid

Quote:
In aqueous solution, it is a weak acid (pKa1 = 7.21, pKa2 = 11.54), and decomposes to nitrous oxide and water with a half life of 16 days at 25 °C at pH 1–3


Alkyl hyponitrites can also be prepared from silver(I)hyponitrite and alkyl halides. Some of them have energetic properties, methyl hyponitrite can only be handled in solution. According to J. Org. Chem. 48 (1983) 3728-33 (doi:10.1021/jo00169a023) they are a convenient source of alkoxyl radicals.


alkyl hyponitrites.png - 96kB

[Edited on 14-5-2021 by dicyanin]




There are more things in heaven and earth,
Horatio,
Than are dreamt of in your philosophy
View user's profile View All Posts By User
