Author: Subject: Cyklonan
Vpatent357
Harmless
*




Posts: 22
Registered: 10-7-2014
Member Is Offline

Mood: No Mood

[*] posted on 8-3-2015 at 15:32


Hi Laboratory of Liptakov,
First, thank you for your research on new kit-explosives easy to do and your innovations.

Cyklonan 1 seems to be the easiest but is it powerful ? (good booster for example?)
And 300 mg of silver acetylide/nitrate primary are sufficient for the complete detonation of one cube? i don't have ETN,PETN,MHN...

For NC, ping-pong balls lacquer can be used?




Small blasting caps, fingers safe!
View user's profile View All Posts By User
Laboratory of Liptakov
International Hazard
*****




Posts: 1376
Registered: 2-9-2014
Location: Technion Haifa
Member Is Offline

Mood: old jew

[*] posted on 10-3-2015 at 14:06


Hi Patent :-)
Ping pong balls? Sure, of course. In 90 g of acetone dissolved 10 g balls. Ag binary salt primer? Unfortunately, I do not know. Untested. But I think, 300mg will be good kick. Or 0,2-0,3g HMTD, of course. Yes, Cyklonan (1 cube) is a good booster for AN /fuel/ Al mixture. Coming soon you see Ammonium nitrate, special fuel without nitro esters composition on only primary 0,5g sensitive.
...:cool:...LL

[Edited on 10-3-2015 by Laboratory of Liptakov]
View user's profile View All Posts By User
Vpatent357
Harmless
*




Posts: 22
Registered: 10-7-2014
Member Is Offline

Mood: No Mood

[*] posted on 10-3-2015 at 14:36


It remains for me to synthesize TACN
From what I know, it is secondary explosive. Is it safe to handle and store dry powder? more sensitive than ETN / PETN? for example

You have already experimented cyklonan with NC ping pong balls? it is of low quality and contains camphor ..

It's perfect :cool: I looking for exactly this kind of boost for AN mixtures, thank I follow your youtube channel very closely

[Edited on 10-3-2015 by Vpatent357]




Small blasting caps, fingers safe!
View user's profile View All Posts By User
Laboratory of Liptakov
International Hazard
*****




Posts: 1376
Registered: 2-9-2014
Location: Technion Haifa
Member Is Offline

Mood: old jew

[*] posted on 11-3-2015 at 11:45


Cyklonan 1 is similar sensitivity, low sensitivity as PETN. I see that Cyklonan works. Thank you for using Cyklonan explosive....:cool:...LL
View user's profile View All Posts By User
Trotsky
Hazard to Others
***




Posts: 166
Registered: 6-2-2013
Location: US
Member Is Offline

Mood: No Mood

[*] posted on 11-3-2015 at 21:53


Why would you use ping pong balls for a nitrocellulose source? I don't get how you've got silver acetylide, but have to resort to ping pong balls for NC? Nitrocellulose is ridiculously easy to synthesize, everything you need to do it is readily available, just sulfuric acid, some nitrate salt, and cotton balls, sodium carbonate or even bicarbonate to neutralize when you're finished. You don't have to watch the temp very close, if you make any attempt at all to keep it cool you should have zero risk of runaway, especially with a small batch. And even if you have a runaway you're not at risk of accidental explosion…
View user's profile Visit user's homepage View All Posts By User
Vpatent357
Harmless
*




Posts: 22
Registered: 10-7-2014
Member Is Offline

Mood: No Mood

[*] posted on 12-3-2015 at 11:49


Because I'm in the same approach as Dr. Liptakov,that is to say, Created my explosives as simply as possible with materials easily accessible and without nitration ..

Yes SA.DS is very easy to do and effective as a primary, TACN seems very easy to produce secondary, even though we know nothing about him (sensibility, storage..)

I can only find ammonia 20% and not 25%, it can work for the synthesis TACN? And are there specific recommendations for synthesis?






Small blasting caps, fingers safe!
View user's profile View All Posts By User
Laboratory of Liptakov
International Hazard
*****




Posts: 1376
Registered: 2-9-2014
Location: Technion Haifa
Member Is Offline

Mood: old jew

[*] posted on 13-3-2015 at 13:33


Of course, only 20% NH3OH no problem to use. Because during the reaction concentration is decreasing. Perhaps 15%, perhaps only 10% at end of reaction. That is no problem. The entire reaction works in a wide range. 10-40 g Cu wire. 50-120 g NH4NO3 dissolved. 100 -150 g NH3OH 15-25%. The temperature reaction range 10-50 Celsius. 30 degrees Celsius is optimum, the optimum of 30 g of Cu, 100 g NH4NO3 optimum, 140 g NH3OH in aqa optimum concentration of 20-25%. After cooling on 5C, separe on fine sieve. Dry. and etc. by Liptakov Channel..:cool:...LL
View user's profile View All Posts By User
PHILOU Zrealone
International Hazard
*****




Posts: 2893
Registered: 20-5-2002
Location: Brussel
Member Is Offline

Mood: Bis-diazo-dinitro-hydroquinonic

[*] posted on 14-3-2015 at 05:06


Quote: Originally posted by Laboratory of Liptakov
Of course, only 20% NH3OH no problem to use. Because during the reaction concentration is decreasing. Perhaps 15%, perhaps only 10% at end of reaction. That is no problem. The entire reaction works in a wide range. 10-40 g Cu wire. 50-120 g NH4NO3 dissolved. 100 -150 g NH3OH 15-25%. The temperature reaction range 10-50 Celsius. 30 degrees Celsius is optimum, the optimum of 30 g of Cu, 100 g NH4NO3 optimum, 140 g NH3OH in aqa optimum concentration of 20-25%. After cooling on 5C, separe on fine sieve. Dry. and etc. by Liptakov Channel..:cool:...LL

NH4OH not NH3OH!




PH Z (PHILOU Zrealone)

"Physic is all what never works; Chemistry is all what stinks and explodes!"-"Life that deadly disease, sexually transmitted."(W.Allen)
View user's profile View All Posts By User
Laboratory of Liptakov
International Hazard
*****




Posts: 1376
Registered: 2-9-2014
Location: Technion Haifa
Member Is Offline

Mood: old jew

[*] posted on 14-3-2015 at 05:32


Of course, NH4OH, thanks Philou, I'm sorry....:o...:cool:...LL
View user's profile View All Posts By User
PHILOU Zrealone
International Hazard
*****




Posts: 2893
Registered: 20-5-2002
Location: Brussel
Member Is Offline

Mood: Bis-diazo-dinitro-hydroquinonic

[*] posted on 14-3-2015 at 05:41


Quote: Originally posted by Laboratory of Liptakov
Of course, NH4OH, thanks Philou, I'm sorry....:o...:cool:...LL

No problemo ;)
NH2OH (hydroxylamine) would be nice to experiment with owing to the high VOD of HAN (hydroxylamine nitrate - NH2OH.HNO3 (HO-NH3NO3)) (arround 8000 m/s).

I wonder if it will complexate competitively against NH3 via the NH2, via the OH or like NH2-NH2 with both.

[Edited on 14-3-2015 by PHILOU Zrealone]




PH Z (PHILOU Zrealone)

"Physic is all what never works; Chemistry is all what stinks and explodes!"-"Life that deadly disease, sexually transmitted."(W.Allen)
View user's profile View All Posts By User
Marcello0922
Harmless
*




Posts: 4
Registered: 15-8-2024
Member Is Offline


[*] posted on 11-9-2024 at 09:52


Quote: Originally posted by Rosco Bodine
@ LL I agree about the possibility of a mixed salt of TACN and TACP being the product. A synthesis of TACP which I described many years ago and posted again recently uses Cu(NO3)2 as precursor for TACP, however the yield resulting is lower than what would be quantitative for the desired TACP.



If you are synthesizing TACP using Cu(NO3)2 then the final reaction produces about 90% TACP and 10% TACN - I have tested this several times using XRD.

Synthesis of TACP with NH4ClO4, CuO and NH3(aq) gives a pure product. XRD showed that [Cu(NH3)4](ClO4)2 is then formed as a deformed octahedron.

The most interesting thing is that with the above method and the addition of hexamine, the reaction proceeds even at room temperature (reaction catalyst?), while the XRD products showed that:

[Cu(NH3)5][NH3](ClO4)3 - crystals in the form of a pyramid with a square base and a perfect trigonal bipyramid. The content of the latter compound was about 86%, while [Cu(NH3)4](ClO4)2 was only 14%.
View user's profile View All Posts By User
Etanol
Hazard to Others
***




Posts: 174
Registered: 27-2-2012
Member Is Offline

Mood: No Mood

[*] posted on 11-9-2024 at 23:13


Quote: Originally posted by Marcello0922

The most interesting thing is that with the above method and the addition of hexamine, the reaction proceeds even at room temperature (reaction catalyst?), while the XRD products showed that:

[Cu(NH3)5][NH3](ClO4)3 - crystals in the form of a pyramid with a square base and a perfect trigonal bipyramid. The content of the latter compound was about 86%, while [Cu(NH3)4](ClO4)2 was only 14%.

[Cu(NH3)5][NH3](ClO4)3 ?
Copper(III) complex?
May be [Cu(NH3)5][NH4](ClO4)3 or [Cu(NH3)4][NH4](ClO4)3 ?
View user's profile View All Posts By User
Marcello0922
Harmless
*




Posts: 4
Registered: 15-8-2024
Member Is Offline


[*] posted on 12-9-2024 at 16:14


The pattern I wrote was confirmed by 3 people - 1 who did the XRD study and 2 who do the spectra resolving. And this was on 5 samples after each synthesis. I know this is strange.

But I have another question by the way: what products can be in the filtrate? In addition to the Schweizer reagent, of course. And unreacted hexamine or ammonium perchlorate.
View user's profile View All Posts By User
Laboratory of Liptakov
International Hazard
*****




Posts: 1376
Registered: 2-9-2014
Location: Technion Haifa
Member Is Offline

Mood: old jew

[*] posted on 13-9-2024 at 09:48


Interesting research of crystalography, Marcello.....With a lot pyamides.
In mother liquor will NH4ClO4, CuO, diluted TACP, diluted hexamine + ammmonium hydroxide. This liquor
is possible evaporate about cca 30 C and obtain next dry energetic material with different (usually slow burned) properties against TACP / CHP.
Mother liquor 10g + 100g dH2O is also possible boil at cca 100 C.

At the high temperature arise fine dry powder CuO, crystalls NH4ClO4+ crystalls hexamine. All gas NH3/4 get out from solution.
At boiling pure TACP mother liquor arise CuO powder + NH4ClO4. All gas NH3/4 get out from solution....:cool:




Development of primarily - secondary substances CHP (2015) Lithex (2022) Brightelite (2023) Nitrocelite and KC primer (2024)
View user's profile View All Posts By User
